HR-01 EdgeServer | HiveRadar

Rethink the Server Form Factor

Traditional servers and tower PCs are holding you back. Legacy infrastructure comes with real trade-offs: from bulky footprints to inflexible deployment options.

Common Challenges in Legacy Deployments

Excessive Power & Cooling

Older systems tend to draw more power and emit more heat, straining energy budgets and cooling systems.

Rigid Deployment

Moving or repurposing a traditional server takes time, effort, and often downtime.

Space Inefficiency

Full-size towers or rack servers dominate valuable desk or rack space.

Delayed Recovery

Replacing or servicing larger systems can be slower, increasing downtime risk during hardware failures.

Cable Management Overhead

Larger setups typically mean more cabling, more clutter, and more potential points of failure.

Meet the HR-01: Enterprise-Class Performance in a Small Form Factor

Designed for modern IT environments, the HR-01 delivers server-grade power and connectivity — without the bulk.

HR-01 size comparison vs traditional 1U server

Whether deployed on a desktop, in a cabinet, or at the edge, it reduces your hardware footprint while maintaining performance, efficiency, and flexibility.

Compact chassis, high-performance internals
Intel Core i9-13900H 14 Core 20 Thread CPU
Up to 96GB RAM and PCIe 4.0 expansion
Up to 24TB of SSD Storage
Ideal for virtualization, edge computing, or branch infrastructure
Lower power consumption and quieter operation

Dimensions: 7.72 × 7.44 × 1.89 inches | 196 × 189 × 48 mm

General Specifications

Powered by a high-performance 13th Gen Intel Core i9 processor, the HR-01 delivers exceptional compute power in a compact form factor. It supports up to 24TB of SSD storage and 96GB of DDR5 memory, offering outstanding expandability for demanding workloads.

Intel 13th Generation Core i9 CPU

The Most Powerful

Onboard X710 10 Gigabit Dual Ethernet Ports

Dual 2.5G Ports on Board

Dual 2.5G RJ45 network ports

Dual USB4

Full 40G and supports 20G Thunderbolt Ethernet.

Standard PCIe Interface

PCIe 4.0 x16 expansion slot

Triple Solid State

SUPPORT RAID0/RAID1

Loaded with I/O for Your Extreme Workloads

Front Panel

Power Switch Audio Jack 1× USB3 Type-A 2× USB2 Type-A

Rear Panel

2× 10Gbps SFP+ 2× 2.5Gbps RJ45 2× USB4 40Gbps Type-C 1× HDMI 2.0 2× USB3 Type-A DC 19V

High Expandability

PCIe 4.0 x16 Slot

The HR-01 includes a PCIe 4.0 x16 slot (electrically x8, 128 GT/s), offering robust support for expansion cards such as GPUs, high-speed NICs, storage controllers, and PCIe-based KVM-over-IP cards — all within a compact mini-server design.

This enables tailored performance for use cases that demand high throughput, low latency, and remote manageability, including:

AI inference and edge computing
Virtualization and lightweight hyper-converged deployments
Video processing, 3D modelling, and simulation workloads
Remote system access and control via KVM-over-IP for out-of-band management

Compatible GPUs: NVIDIA T1000 8GB, Radeon Pro WX3200, Intel Arc A40

M.2 NVMe SSD Slots

The HR-01 supports up to three M.2 NVMe SSDs, with each slot accommodating drives up to 8TB in capacity. The leftmost slot is PCIe 4.0 compatible, offering maximum transfer speeds of up to 7000MB/s for high-performance storage needs.

The system supports both RAID 0 for increased storage capacity and performance, and RAID 1 for enhanced data redundancy and protection.

U.2 NVMe SSD Support

The HR-01 also supports enterprise-grade storage configurations, allowing expansion up to 24TB using a combination of one U.2 NVMe SSD and two M.2 22110 NVMe SSDs.

This setup meets the needs of professionals requiring high-capacity, high-performance storage for demanding workloads such as data analysis, content creation, and virtualization.

Included SFP+ Transceiver Options

Pre-populated with copper transceivers at no extra charge. Prefer fiber or DAC? Alternate options available upon request, subject to availability.

Copper RJ45 SFP+

Auto-negotiating
10G / 5G / 2.5G / 1G

Fiber MMF SR

Short-range multimode
Up to 300m

DAC Cable

Direct-attach copper
1.5M length

Technical Specifications

Component	Specification
CPU	Intel® Core™ i9-13900H (13th Gen, vPro® Enterprise)
Graphics	Intel® Iris® Xe Graphics (eligible)
Memory	Up to 96GB DDR5-5200MHz (Dual Channel, 2× SODIMM slots)
Storage (SSD)	1× M.2 2280 NVMe (PCIe 4.0 x4, Alt U.2) 1× M.2 2280/22110 NVMe (PCIe 4.0 x4) 1× M.2 2280/22110 NVMe (PCIe 3.0 x2)
Max Storage Capacity	Up to 24TB
RAID Support	RAID 0 (performance) and RAID 1 (redundancy)
Expansion Slot	1× PCIe 4.0 x16 (half-height, single-slot, supports up to x8 speed)
Ethernet	2× 10Gbps SFP+ ports (Preloaded with copper or fibre transceivers.) 2× 2.5Gbps RJ45 ports
Wireless Connectivity	M.2 2230 Wi-Fi 6 + Bluetooth 5.2
Video Output	1× HDMI 2.0 (4K @ 60Hz) 2× USB4 (8K @ 30Hz, Alt DisplayPort)
Audio Output	HDMI audio, 1× 3.5mm combo jack
I/O Ports	2× USB 3.2 Gen2 Type-A 1× USB 3.2 Gen1 Type-A 2× USB 2.0 Type-A 2× USB4 (Alt PD) 1× HDMI, 1× 3.5mm combo jack
Power Supply	19V DC (Power adapter included)
Operating System	Multiple OS options available (Windows 11, Linux, or custom image)
Dimensions	7.72 × 7.44 × 1.89 inches \| 196 × 189 × 48 mm
Included in Box	Main Unit, Power Adapter + Cable, U.2 Conversion Plate, SSD Heat Sink, Mounting Screw, HDMI Cable, User Manual

Server Rack Mounting Option

HiveRadar custom 2-node rack with LED-lit enclosure

Whether you're running the HR-01 as a standalone edge server or deploying it with HCI platforms like Scale Computing, StorMagic, Azure Local, or Proxmox, elevate your setup with our custom-designed 2-node rack.

Featuring a sleek LED-lit enclosure with custom iconography and a futuristic light tint, this rack doesn't just house your hardware — it turns your deployment into a visual statement. Perfect for tech showrooms, live demos, or any production environment where appearance matters as much as performance.

Form meets function. Light up your edge.
